Fiberglass Direct Roving Glass Fiber Roving, 200tex-9600tex FRP
fiberglass direct roving, Fiberglass Direct Roving / Filiament for Weave/Winding, China fiberglass direct roving
Description
Basic Info
- Model NO.: ECR
- Technique: Winding Filament Roving
- Surface Treatment: Vinyl Coated
- Filament Diameter: 11-25um
- Finish: Sizing
- Transport Package: Carton/Pallet
- Origin: Changzhou, China
- Certification: CE, ISO, Dnv CCS
- Yarn Structure: Single Yarn
- Fiberglass Type: E-Glass
- Plt: 1120*1120mm
- Trademark: TIANMA
- Specification: 48-64roll/plt
- HS Code: 7019120090
Product Description
Brief introduction
Used for reinforncement of unsaturated polyester resin,vinyl ester resin,epoxy resin etc. Used in FRP widing pipe,pultrusion process.
Data sheet
Packing ,storage and tranpoartation
1. Shrinkage polyesterbag,3-4 layers for each carton,48-64rolls/carton
2. Storage temperature: 5-36ºC,Moisture degree :35-65%,Max.two layers/pallet.Allowed vertically stacked if the storage space is limited.Used for reinforncement of unsaturated polyester resin,vinyl ester resin,epoxy resin etc. Used in FRP widing pipe,pultrusion process.
Used for reinforncement of unsaturated polyester resin,vinyl ester resin,epoxy resin etc. Used in FRP widing pipe,pultrusion process.
Data sheet
| Specifications | Linear Density Tex | Tolerance % | Moisture Content% | Size Content% | Breaking Strength N/tex |
| EDR-200-T906 | 200 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-300-T906 | 300 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-400-T908 | 400 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-500-T908 | 500 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-600-T908 | 600 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-900-T908 | 900 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-1000-T908 | 1000 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-1200-T908 | 1200 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-1500-T908 | 1500 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-2000-T908 | 2000 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR2400-T908 | 2400 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-4800-T908 | 4800 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
| EDR-9600-T908 | 9600 | ±5 | ≤0.20 | 0.50±0.20 | ≥0.35 |
Packing ,storage and tranpoartation
1. Shrinkage polyesterbag,3-4 layers for each carton,48-64rolls/carton
2. Storage temperature: 5-36ºC,Moisture degree :35-65%,Max.two layers/pallet.Allowed vertically stacked if the storage space is limited.Used for reinforncement of unsaturated polyester resin,vinyl ester resin,epoxy resin etc. Used in FRP widing pipe,pultrusion process.
